The world's fastest camera: Trillion-frame-per-second video
By using optical equipment in a totally unexpected way, MIT researchers have created an imaging system that makes light look slow
MIT researchers have created a new imaging system that can acquire visual data at a rate of one trillion exposures per second. That’s fast enough to produce a slow-motion video of a burst of light traveling the length of a one-liter bottle, bouncing off the cap and reflecting back to the bottle’s bottom.
Media Lab postdoc Andreas Velten, one of the system’s developers, calls it the “ultimate” in slow motion: “There’s nothing in the universe that looks fast to this camera,” he says.
The system relies on a recent technology called a streak camera, deployed in a totally unexpected way. The aperture of the streak camera is a narrow slit. Particles of light — photons — enter the camera through the slit and pass through an electric field that deflects them in a direction perpendicular to the slit. Because the electric field is changing very rapidly, it deflects late-arriving photons more than it does early-arriving ones.
The image produced by the camera is thus two-dimensional, but only one of the dimensions — the one corresponding to the direction of the slit — is spatial. The other dimension, corresponding to the degree of deflection, is time. The image thus represents the time of arrival of photons passing through a one-dimensional slice of space.
The camera was intended for use in experiments where light passes through or is emitted by a chemical sample. Since chemists are chiefly interested in the wavelengths of light that a sample absorbs, or in how the intensity of the emitted light changes over time, the fact that the camera registers only one spatial dimension is irrelevant.
But it’s a serious drawback in a video camera. To produce their super-slow-mo videos, Velten, Media Lab professor Ramesh Raskar and Moungi Bawendi, the Lester Wolfe Professor of Chemistry, must perform the same experiment — such as passing a light pulse through a bottle — over and over, continually repositioning the streak camera to gradually build up a two-dimensional image. Synchronizing the camera and the laser that generates the pulse, so that the timing of every exposure is the same, requires a battery of sophisticated optical equipment and exquisite mechanical control. It takes only a nanosecond for light to scatter through a bottle, but it takes about an hour to collect all the data necessary for the final video. For that reason, Raskar calls the new system “the world’s slowest fastest camera.”
Media Lab postdoc Andreas Velten, left, and Associate Professor Ramesh Raskar with the experimental setup they used to produce slow-motion video of light scattering through a plastic bottle.
M. Scott Brauer
Doing the math
After an hour, the researchers accumulate hundreds of thousands of data sets, each of which plots the one-dimensional positions of photons against their times of arrival. Raskar, Velten and other members of Raskar’s Camera Culture group at the Media Lab developed algorithms that can stitch that raw data into a set of sequential two-dimensional images.
The streak camera and the laser that generates the light pulses — both cutting-edge devices with a cumulative price tag of $250,000 — were provided by Bawendi, a pioneer in research on quantum dots: tiny, light-emitting clusters of semiconductor particles that have potential applications in quantum computing, video-display technology, biological imaging, solar cells and a host of other areas.
The trillion-frame-per-second imaging system is a spinoff of another Camera Culture project, a camera that can see around corners. That camera works by bouncing light off a reflective surface — say, the wall opposite a doorway — and measuring the time it takes different photons to return. But while both systems use ultrashort bursts of laser light and streak cameras, the arrangement of their other optical components and their reconstruction algorithms are tailored to their disparate tasks.
Because the ultrafast-imaging system requires multiple passes to produce its videos, it can’t record events that aren’t exactly repeatable. Any practical applications will probably involve cases where the way in which light scatters — or bounces around as it strikes different surfaces — is itself a source of useful information. Those cases may, however, include analyses of the physical structure of both manufactured materials and biological tissues — “like ultrasound with light,” as Raskar puts it.
As a longtime camera researcher, Raskar also sees a potential application in the development of better camera flashes. “An ultimate dream is, how do you create studio-like lighting from a compact flash? How can I take a portable camera that has a tiny flash and create the illusion that I have all these umbrellas, and sport lights, and so on?” asks Raskar, the NEC Career Development Associate Professor of Media Arts and Sciences. “With our ultrafast imaging, we can actually analyze how the photons are traveling through the world. And then we can recreate a new photo by creating the illusion that the photons started somewhere else.”
